TODO-MATIC – Dry-break Couplings

TODO-MATIC dry-break couplings have a long-standing reputation for managing oil, gas, and petrochemicals with over 30 years of expertise. This market leader is known for its versatility and was one of the pioneers to adopt the NATO STANAG 3756 standard. The TODO-MATIC coupling guarantees safe operation with minimal residue loss and virtually no spillage, resulting in more product delivery to customers and increased profit margins for handlers.

Features & Benefits

TODO-MATIC couplings are recognised as ‘best in class’ couplings and are used across many different sectors. Some of the benefits include:

• Available in 62 sizes
• High-grade materials
• Minimum operator intervention required
• Ability to handle aggressive fluids
• Minimal residue loss & virtually zero spillage
• Proven & trusted in the field

Variants & Technological Information

TODO’s dry-break coupling has been designed and innovated to suit specific needs, so offer a range of different metal and O-ring grades to ensure no application is left beyond reach.

TODO’s systems are manufactured to operate and remain reliable under challenging conditions, even after repeated use. All TODO-MATIC dry-break coupling units can withstand a working temperature range of -20 to +80 degrees C (-4 to +176 Fahrenheit), allowing them to cover virtually every application in the field. Working pressures will vary according to the material used, but please note that working pressures are reduced for flanged products according to their individual pressure rating.

Max. Working Pressure – Up to 25 bar (363 psi)

Product Test Pressure – Up to 37.5 bar (544 psi)

Standard Working Temperature – -20 to +80 degrees C (-4 to +176 fahrenheit)

Optional Working Temperature – -45 to +150 degrees C (-49 to +302 fahrenheit)

Applications

For many years, TODO-MATIC dry-break couplings have been a safe, efficient, and reliable solution for transferring valuable and hazardous products, including potable water and hydrochloric acid. With minimal operator involvement, loading and unloading is streamlined, making it ideal for various applications, including road, rail, offshore rigs, and ships.

Caps, Plugs & Accessories

We offer a range of caps and plugs for TODO-MATIC tank and hose units to suit your specific application, allowing you total peace of mind. TODO has designed these to keep debris away from key areas when connections are not engaged. Materials include:

• 1″ (DN25), 2″ (DN50) & 3″ (DN80): Aluminium, Brass, Rubber, Stainless Steel
• 5″ (DN65) & 4″ (DN100): Aluminium, Brass, Stainless Steel
• 6″ (DN150): Aluminium, Stainless Steel
